CLI all the things: Introducing Josh.js

Everytime I click my way through a hierarchy tree, I long for a simple BASH shell with TAB completion. It's such a simple thing, but TAB completion (usually implemented via the trusty Readline library) still ranks as one of the most productive tools in my book. So as I was once again trying to navigate to some page in a MindTouch site, I thought that all I really want is to treat this documentation hierarchy like a file system and mount it with a bash shell. Shortly after that I'd implemented a command line interface using our API and Miguel DeIcaza's C# Readline inspired library, GetLine. But I couldn't stop there, I wanted it built into the site itself as a Quake-style, dropdown console. I figured that this should be something that already exists in the javascript ecosystem, but alas, I only found a number of demos/implementations tightly integrated into whatever domain they were trying to create a shell for. The most inspired of them was the XKCD shell, but it also was domain specific. Worst of all, key-trapping and line editing was minimal and none of them even trapped TAB properly, leaving me with little interest in using any of them as a base for my endeavours.

Challenge Accepted


Thus the challenge was set: I wanted a CLI w/ full Readline support in the browser for every web project I work on. That means TAB completion, emacs-style line editing, killring and history with reverse search. Go! Of course, some changes from a straight port of Readline had to be made: Commands needed to work using callbacks rather than synchronous. History needed to go into LocalStorage so it would survive page reloads, Killring wouldn't co-operate with the clipboard. But other than that it was all workable, including a simple UI layer to deal with prompts, etc., to create a BASH-like shell.


The result of this work is the Javascript Online SHell, a collection of building blocks for adding a command line interface to any site: Readline.js handles all the key-trapping to implement full Readline line editing. History.js is a simple command history backed by localstorage. Killring.js implements the cut/paste history mechanism popular in old skool, pre-clipboard unix applications. Shell.js provides the UI layer to quickly create a console in the browser and, finally, Pathhandler.js implements cd, pwd, ls and filepath TAB completion with simple hooks to adapt it to any hierarchy. The site for josh.js provides detailed documentation and tutorials from the hello world scenario to browsing github repos as if they were local git file systems.

Go ahead, type ~ and check it out

For the fun of it, I've added a simple REST endpoint to this blog to get basic information for all published articles. Since I already publish articles using a YYYY/MM/Title naming convention, I turned the article list into a hierarchy along those path delimiters, so it can be navigated like a file system like this:


In addition I added a command, posts [n], to created paged lists of articles and a command, go, to navigate to any of these articles. Since the information required (e.g. id, title, path) is small enough to load quickly in its entirety, I decided to forego the more representative use of Josh.js with a REST callback for each command/completion and instead load it all at initialization and operate against the memory model. I wrote a 35 line node.js REST API to serve up the post json which is called on the first console activation, takes the list of articles and builds an in-memory tree of the YYYY/MM/Title hierarchy:

var config = require('../config/app.config');
var mysql = require('mysql');
var _ = require('underscore');
var connection = mysql.createConnection({
  host: 'localhost',
  database: config.mysql.database,
  user: config.mysql.user,
  password: config.mysql.password
var express = require('express');
var app = express();
app.configure(function() {
app.get("/posts", function(req, res) {
    "SELECT ID, post_title, post_name, post_date " +
      "FROM wp_posts " +
      "WHERE post_status = 'PUBLISH' AND post_type = 'post' " +
      "ORDER BY post_date DESC",
    function(err, rows, fields) {
      if(err) throw err;
      res.send(, function(row) {
        return {
          id: row.ID,
          name: row.post_name,
          published: row.post_date,
          title: row.post_title

Implementing unix filesystem style navigation in the console is as simple as adding Josh.PathHandler to the shell and providing implementations of getNode(path, callback) and getChildNodes(node, pathParts, callback). These two functions are responsible for finding nodes by path and finding a node's children, respectively, which is the plumbing required for pwd, ls, cd and TAB completion of paths. The posts command is even simpler: Since it only takes an optional numeric argument for the page to show, there is no completion handler to implement. The execution handler simply does a slice on the array of articles to get the desired "page", uses to first transform the data into the viewmodel and then renders it with underscore.template:

_shell.setCommandHandler("posts", {
  exec: function(cmd, args, callback) {
    var arg = args[0];
    var page = parseInt(arg) || 1;
    var pages = Math.ceil(_posts.length / 10);
    var start = (page - 1) * 10;
    var posts = _posts.slice(start, start + 10);
      posts:, function(post) {
        return {id:, date: formatDate(post.published), title: post.title}
      page: page,
      pages: pages

The final addition is the go command which acts either on the current "directory" or the provided path. Since any argument is a path, go gets to re-use Josh.PathHandler.pathCompletionHandler which ls and cd use.

_shell.setCommandHandler('go', {
  exec: function(cmd, args, callback) {
    return _pathhandler.getNode(args[0], function(node) {
      if(!node) {
        callback(_shell.templates.not_found({cmd: 'go', path: args[0]}));
      } else {
        root.location = '/geek/blog'+node.path;
  completion: _pathhandler.pathCompletionHandler

Once called, the appropriate node is resolved and the path of the node used to change the window location. The console uses localStorage to track the open state of the console, so that navigating to a new page re-opens the console as appropriate while the page location is used to initialize the current directory in the console. The help, clear and history commands come for free.

Oh, and then there is wat? as a go shortcut to get to this article :)

What's next?

Go ahead, play with it, let me know whether there are assumptions built in that prevent your favorite console scenario. For reference and those interested in the nitty gritty, the full, annotated source for the console I use on this blog can be found here. Most of the lift is done by Josh.js, and its fairly simple to get your own console going. Check out the documentation here along with the tutorials that walk through some usage scenarios.

Josh.js is certainly ready for use and deployment, but until it's been put through its paces a bit more to figure out what's working and what's not, the API is still open for significant changes. I'm tracking things I am planning to do or working on via GitHub Issues. Please submit any problems there as well, or even better, provide a pull request. I hope my love for CLIs on websites will inspire others to do the same for their applications. I certainly will endeavour to include a shell in every web project I undertake for the forseeable future.

Using lambda expression with .OrderBy

It's always bugged me that I could use a lambda expression with List<T>.Sort(), but not with IEnumerable<T>.OrderBy, i.e. given data object Data:

public class Data {
  public int Id;
  public string Name;
  public int Rank;

you can sort List<Data> in place like this:

data.Sort((left, right) => {
var cmp = left.Name.CompareTo(right.Name);
  if(cmp != 0) {
    return cmp;
  return right.Rank.CompareTo(left.Rank);

But if I had an IEnumerable<Data>, orderby needs a custom IComparer and can't take a lambda.

Fortunately, it is fairly easy to create a generic IComparer that does take a lambda and an extension method to simplify the signature to just a lambda expression:

public static class OrderByExtension {
    private class CustomComparer<T> : IComparer<T> {
        private readonly Func<T,T,int> _comparison;

        public CustomComparer(Func<T,T,int> comparison) {
            _comparison = comparison;

        public int Compare(T x, T y) {
            return _comparison(x, y);

    public static IEnumerable<T> OrderBy<T>(this IEnumerable<T> enumerable, Func<T,T,int> comparison) {
        return enumerable.OrderBy(x => x, new CustomComparer<T>(comparison));

    public static IEnumerable<T> OrderByDescending<T>(this IEnumerable<T> enumerable, Func<T,T,int> comparison) {
        return enumerable.OrderByDescending(x => x, new CustomComparer<T>(comparison));

Now I can use a lambda just like in sort:

var ordered = unordered.OrderBy((left, right) => {
    var cmp = left.Name.CompareTo(right.Name);
    if(cmp != 0) {
        return cmp;
    return right.Rank.CompareTo(left.Rank);

Of course, .OrderByDescending is kind of redundant, since you can invert the order in the lambda just as easily, but is added simply for completeness.

Implicits instead of Extension Methods?

After the latest round of scala is teh complex, I started thinking a bit more about the similar roles implicit conversions in scala play to extension methods in C#. I can't objectively comment on whether Extension Methods are simpler (they are still a discoverability issue), but I can comment that the idea of implicit conversion to attach new functionality to existing code really intrigued me. It does seem less obvious but also a lot more powerful.

Then i thought, wait, C# has implicit.. Did they just invent extension methods without needing to? I've never used implicit conversion in C# for anything but automatic casting, but maybe I was just not imaginative enough. So here goes nothing:

public class RichInt {
  public readonly int Value;

  public static implicit operator RichInt(int i) {
    return new RichInt(i);

  public static implicit operator int(RichInt i) {
    return i.Value;

  private RichInt(int i) {
    Value = i;

  public IEnumerable<int> To(int upper) {
    for(int i = Value;i<=upper;i++) {
      yield return i;

Given the above I was hoping I could mimic scala's RichInt to() method and write code like this:

foreach(var i in 10.To(20)) {

Alas that won't compile. Implicit conversion only works on assignment, so i had to write

foreach(var i in ((RichInt)10).To(20)) {

So I do have to use an extension method to create To() in C#.

And, yes, i'm grossly simplifying what scala's implicts can accomplish. Also, I wish I could have block scope using statements to import extension methods for just a block the way scala's import allows you to handle local scope implicits.

Using log4net without requiring it as a dependency

Logging, to me, is a basic requirement of any code I write. There's nothing more useful to track down an odd bug than being able to turn on debug logging in production, potentially filter it down to the area of interest and get some real live data. When that code is causing trouble at a customer location, this capability becomes worth its weight in gold.

And while I am a big Interface abstraction and IoC nut, logging is so fundamental to me that I do use a static logger instance in every class and just have a hard requirement for log4net. I just want this to work and not have people worry about having to inject an ILog into my classes, forcing them to think about a concern of mine. It's far less obtrusive this way, imho.

But it does mean that no matter how small and compact my code is, i suddenly tack on a ~240KB dll requirement, often several times larger than my own code. And there goes my "i don't want them to worry about a concern of mine" out the window.

Depending on log4net only when it's there

That got me thinking about how I can avoid this dependency. I knew that if my code path doesn't hit a code in a referenced DLL, the absense of the DLL does not cause a problem. Of course that means i can't even reference their interfaces.

Instead I had to create a duplicate of the log4net ILog interface and proxy my calls to it. The result is a single file, Logger.cs with the following wire-up:

internal static class Logger {

  private static readonly bool _loggingIsOff = true;

  static Logger() {
    try {
        _loggingIsOff = false;
    } catch {}

  public static ILog CreateLog() {
    var frame = new System.Diagnostics.StackFrame(1, false);
    var type = frame.GetMethod().DeclaringType;
    return _loggingIsOff ? (ILog)new NoLog() : new Log4NetLogger(type);

(Full code is here)

Because it's not supposed to create a dependency, it's marked internal. Yes, that means that every assembly has a copy of it, but that's really not significant in the grand scheme of things. In returns for a couple of redundant bytes, I can now do add a logger to every class simply with:

private static readonly Logger.ILog _log = Logger.CreateLog();

And if log4net is present and configured, commence the flow of debug statements. Meanwhile I can ship my code without the log4net DLL.

Simple Immutable objects

I'm currently at #monospace and over lunch was discussing message passing with @ackenpacken and @briandonahue. I was lamenting that to create an immutable object in C# was just a lot harder than a mutable one. You either have to create a builder of sorts or create very verbose constructors and never mind trying to derive a new immutable instance with just one field changed. I suggested that if only private setters could be used with object initializers, this would be solved and realized that I could just use anonymous objects as my initializers and so after finishing with talks for the day I coded up a proof of concept.

// create a new data class
public class Person {
  public int Id { get; private set; }
  public string Name { get; private set; }

So this is a perfectly good immutable object. So good, we can't even initialize it. Enter Droog.ImMutie.Immutable:

// create and instance
var person = Immutable.Create<Person>(new {Id = 43, Name = "Bob"});

The argument to Immutable.Create is simply object, so we can pass in an anonymous object with whatever properties we want. Create then provides and instance and copies over values on property name and type match. And if we want to change the Name?

// derive new instance with different name (using extension method)
person = person.With(new {Name = "Robert"});

With let's you provide a new anonymous object, will clone the previous instance and then overwrite each newly provided field by name/type match.

Very simple, no error checking, not the most efficient code, but it works and you can get it from github :)

Easily add Pre and Post build tasks to a Visual Studio Solution

One dirty little secret about Visual Studio 2008 and even Visual Studio 2010 is that while MSBuild governs the solution build process, the .sln file is not an MSBuild file. The .*proj files are, but solution isn't. So trying to customize the build on the solution level seemed really annoying.

As I dug around trying to find the Solution level equivalent of the Build Events dialog from Visual Studio, Sayed Ibrahim pointed out that in Visual Studio 2010 there is now a hook to let you inject some before and after tasks, but unfortunately the problem I was trying to solve was the build process for MindTouch DReAM, which is still in Visual Studio 2008.

Approach 1: Generating the solution msbuild .proj

Digging around further, I found out that you could get the MSBuild file that the solution was turned into. By setting the environment variable MSBuildEmitSolution=1 and running MSBuild will write out the generated .proj file.

While this enables you to edit it and add new tasks, it means that your build script will drift out of sync with the solution as it is modified. I initially went down this path, since the build i wanted was very specialized to the distribution build. That let me eliminate 90% of the .proj file and I felt confident that the smaller the .proj, the simpler it would be to keep it in sync with the solution.

Approach 2: Calling the solution from a different build script

But wait, all the solution .proj did was call MSBuild on each of its projects. So if one MSBuild script can call another, why do i even need to use a generated version of the solution? Turns out you don't. You can write a very simple MSbuild script, that in turn calls the .sln, letting MSBuild perform the conversion magic, and you still get your pre and post conditions.

<Project DefaultTargets="Build" ToolsVersion="3.5" xmlns="">
    <Target Name="Build">
        <CallTarget Targets="PreBuild"/>
        <CallTarget Targets="Dream"/>
        <CallTarget Targets="PostBuild"/>
    <Target Name="PreBuild">
        <Message Text="Pre Build" />
    <Target Name="PostBuild">
        <Message Text="Post Build" />
    <Target Name="Dream" Outputs="@(DreamBuildOutput)">
        <Message Text="Building DReAM" />
        <MSBuild Targets="Rebuild"
                 Properties="Configuration=Signed Release; Platform=Any CPU; BuildingSolutionFile=true;">
            <Output TaskParameter="TargetOutputs" ItemName="DreamBuildOutput" />
        <Message Text="Done building DReAM" />

Now that I've implemented this, I am surprised that when I looked for a solution, this didn't come up in google and I hope that this post helps the next person that runs into this issue. The only drawback (which it shares with the first approach) is that this script is only for manual execution. Building from within Visual Studio can't take advantage of it.

Ok, so there are still delegates you have to define

Yesterday I needed to create a bit of code that should retry an http request on failure and i wanted this to happen in a non-blocking fashion, so a plain loop was out. Using DReAM's Plug, I can easily set up a .WhenDone handler, but I need something to call back recursively. I could have created a new method that calls itself recursively, but inspired by my recent scala reading, i wanted to define the function to execute to exist only in the scope of the current function. The resulting code was this:

public void Restart(string wikiId) {
    Action restarter = null;
    var retry = 0;
    restarter = () => {

        // call the stop endpoint
        _self.At("host", "stop", wikiId)
            .Post(new Result<DreamMessage>()).WhenDone(
                m => {

                    // if the endpoint was unavailable and we've got retries left ...
                    if(m.Status == DreamStatus.ServiceUnavailable && retry <= 3) {

                        // ... sleep for 2 seconds ...
                        Async.Sleep(2.Seconds()).WhenDone(r => {

                            // ... then try again
                e => {
                    // plug's don't throw exceptions, they communicate failure in the resulting message

    // kick the restart attempt off

Completely non-blocking, yay. Of course, like most continuation based async code, it has a tendency to walk off the right side of the screen, but that's a different topic.

Discussing this pattern, Steve suggested that instead of explictly calling myself to execute the next retry, the Action should take another action as its argument. By passing continuation in, any kind of continuation could be called, even a no-op that terminates the chain.

Ok, cool, let's just change the signature of restarter to Action<Action>... no wait, it need to be an action that takes and action that takes an action, that.... hrm, you see the problem...

Action<Action<Action<Action<_ad infinitum_>>>>

I needed a recursive delegate definition and that is simply not possible with Func<> and Action<>. I needed something like:

delegate void Recursor(Recursor continuation)

So, unlike my previous statement, there are still scenarios where you have to write a delegate :)

It's all about messages and pattern matching

My inability to cleanly insert an intercepting actor to spawn new actors on demand discussed in my previous post about Calculon illustrated tunnelvision in my expression based messages. While these are a great way to express the message contract, they are finally just one way of defining message payloads. The pipeline should be ignorant of message payloads and be able to route any payload based on meta-data alone.

Routing revisited

I had to stop hiding the IMessage format under hood and just accept that ExpressionTransport really represents a convenience extension for generating message payloads. This change not only makes it possible for any actor to accept any kind of message, but also to makes the routing a lot simpler and flexible. Now there is only a single, much simpler ITransport:

public interface ITransport {
    ActorAddress Sender { get; }
    void Send(IMessage message);

I've also attached ther sender onto the transport, which means there's one less dependency to inject. Given this, ExpressionTransport and MessageTransport simply becomes extension methods on ITransport:

public static class TransportEx {
    public static void Send<TRecipient>(
       this ITransport transport,
       Expression<Action<TRecipient>> message
    ) {
       transport.Send(new ExpressionActionMessage<TRecipient>(
          ActorAddress.Create<TRecipient>(), message
    // etc.

This provides a lot more flexibility for messaging, since new payloads can be created by implementing IMessage. It does mean that dynamic dispatch would be nice for dispatching the different payloads against their respective receivers. Oh well, we can work around that.

Determining what messages to accept

Now it's possible for an actor not of type TRecipient to receive an ExpressionMessage<TRecipient>, perform some action and re-dispatch it via Send(). By default routing is done by Id, but missing a direct receiver we can now insert additional pattern matching to determine a suitable recipient. For this I've created an interface to let actors expose their accept criteria:

public interface IPatternMatchingActor {
    Expression<Func<MessageMeta, bool>> AcceptCriteria { get; }

While this could have been done by convention, I couldn't think of a reason other than current fashion to not use an interface contract to expose this actor capability, so an interface it was. The reason it's an Expression and operates on the MessageMeta rather than the expression is to facilitate serialization of the criteria for delivery across the process boundary so messages can be qualified for acceptance before attempting to cross that boundary.

Better plumbing

I now have everything I need to switch the bots to Calculon. Once that is done, and working reliably, it'll be time to improve the dispatch plumbing to improve speed and reduce concurrency bottlenecks in dispatch.

Calculon: Building an actor framework

I'm currently extending functionality in the bots and in order to make this easier, I'm refactoring the adhoc actor-like message processing system I built into one a bit more flexible for adding features quickly. Right now message senders and receivers are hard-coupled and use blocking dictionary lookups for dispatch. They also act on instances of each other, which allowed some insidious calls to sneak in during moments of weakness.

As I embarked on my refactor, I wanted to make sure the replacing infrastructure removed assumptions about the entities communicating among each other but also wanted to avoid the pitfall of designing something overly generic. For that I had to first define what it was I needed to be able to do, so I'd only build what I need. At the same time, I decided to pull the replacement into its own Assembly, so that implementation specific coupling wouldn't leak back into the plumbing again. The resulting system has been named in honor of the greatest of all acting robots, Calculon, and is available in its present work-in-progress form on github.

The current actors


The bot is responsible for dispatching messages to users and receiving user messages and presence status. The bot passes messages for a user on to the user's UserAgent actor and receives messages to send to the user from the UserAgent. For distribution and maintenance simplicity, each bot and its related actors was implemented as a separate process.


UserAgents keep the state of the user, such as presence, including all resources (different clients) connected and queues up messages coming from the message queue until the user is in a state to receive messages. It has its own persistence layer, allowing idle users to expire and be recreated as incoming traffic from either the bot or the message queue requires it.


The message queue is a client to our store-and-forward queueing system. Messages from users are pushed into the this actor via long-polling and user data/actions that affect other systems (such as analytics) are pushed into the appropriate queues as they are handed to the MessageQueue by other actors (generally UserAgents).

What capabilities are needed?

Register actors

At the root of the system, exists the Stage, which exposes the ActorBuilder:


The assumption is that actors may require a transport and their own address at construction time and that they are completely isolated, i.e. no reference is ever exposed. The builder will inject these framework owned dependencies if detected in a constructors signature. In order to allow for more flexible construction and the ability to have some kind of IoC container act as a factory, the builder exposes hooks like this:

    (transport,address) => container.Resolve<IXmppAgent>(transport,address)

The above assumes a container such as Autofac which can resolve a type and be provided typed parameters to optionally inject.

Send messages without knowing that a receiver exists

This is the root of the dispatch system. I need to be able to send the message without a reference to receiver and let the transport worry about immediate delivery, queueing for later or routing it to some controller that will bring the recipient into existence. None of those concerns should be visible to the sender. Using semantics introduced in "Type-safe actor messaging approaches", and slightly tweaked by implementation, provides me with a way of asynchronously calling methods on unknown recipients:

public interface IExpressionTransport {
    void Send<TRecipient>(Expression<Action<TRecipient>> message);
    void Send<TRecipient>(Expression<Action<TRecipient, MessageMeta>> message);
    Result SendAndReceive<TRecipient>(Expression<Action<TRecipient>> message);
    Result SendAndReceive<TRecipient>(Expression<Action<TRecipient, MessageMeta>> message);
    Result<TResponse> SendAndReceive<TRecipient, TResponse>(
        Expression<Func<TRecipient, TResponse>> message
    Result<TResponse> SendAndReceive<TRecipient, TResponse>(
        Expression<Func<TRecipient, MessageMeta, TResponse>> message
    IAddressedExpressionTransport<TRecipient> For<TRecipient>(string id);

The main addition is the ability to inject MessageMeta, a class containing meta information such as Sender and Recipient into the receiver without the Sender having to specify this data.

Send/Receive by Id (UserAgent target)

For UserAgent messages, there are thousands of actors each with a unique Id. While currently that Id is a Jid I don't want to tie the internals to Xmpp specific details, so Id should be an plain string and let the transport worry about the meaning and routing implications of that string.

The ability to send by Id is provided by IExpressionTransport.For<TRecipient>(string id). The returned interface IAddressedExpressionTransport<TRecipient> mirrors IExpressionTransport, representing a intermediate storage of the receiver id, thus providing a fluent interface that permits the following calling convention:

_transport.For<Recipient>(id).SendAndReceive(x => x.Notify("hey", "how'd you like that?"));

Send/Receive by Type (XmppBot/MessageQueue targets)

If I stay with the process-per-bot for the bot and messagequeue actors, there would be a single instance for these actors and I can address them directly by Type. The semantics for these message are already expressed by IExpressionTransport.

Spawn UserAgent on demand

Of course, dealing with unkown recipients begs the question where do these recipients come from? I need to be able intercept messages for Id's that are not yet in the system and spawn those recipients on the fly. Wanting to stay with actors for anything but the base plumbing, this facility should be handled by actors that can receive these messages and tell the plumbing to instantiate a new actor.

The same interface to access the ActorBuilder exposed by the stage is encapsulated by the IDirector:

public interface IDirector {
    ActorBuilder<TActor, IDirector> AddActor<TActor>();
    void R(ActorAddress address);

The director being a framework owned actor can of course be called via messaging, allowing a new actor to be registered with:

    x => x.AddActor<IXmppAgent>().WithId("").Build()

That leaves the ability to intercept messages that don't have a recipient, and redispatch those messages once the interceptor was able to spawn the actor. Both of those are not compatible with Expression based messages since they are coupled to a pretty specific contract. This is the one piece I don't have in Calculon at the time of this writing and the problem is discussed below.

Retire UserAgent on Idle

When a UserAgent sits idle for a while, it should be possible to remove it from the actor pool. Since the actor instance doesn't know that anything about the framework that owns it, there needs to be a message that can be sent to the actors mailbox that shuts it down, ideally disposing and IDisposable actors.

The interface IDirector introduced above includes a method for just that:

    (x,m) => x.RetireActor(_address, m);

This could be send by an actor itself, or by a governing actor that is responsible for a number of actors in a pool. Under the hood, this is where un-typed messages come into play, since they can be sent without a matching method on the recipient, and therefore could have special meaning to the mailbox that manages the recipient. I.e. sending the retire message to the director, simply causes it to send an untyped retire message to the actors mailbox, which will then shut itself down and dispose the actor. The interface for untyped messages (providing a more traditional Receive(msg) actor messaging model) is provided by this interface:

public interface IMessageTransport {
    void Send<TMessageData>(TMessageData messageData);
    Result<TOut> SendAndReceive<TIn, TOut>(TIn messageData);
    IAddressedMessageTransport For(string id);

Rather than force an interface on the receiving actor, messages not simply swallowed by the mailbox are delivered to the actor by convention, looking for a Receive method with appropriate TMessageData.

What capabilities are desirable?

The above is the basic requirements to provide the same functionality already present in the bot daemons, but using generalized plumbing. It's certainly sufficient to get the code underway, but in itself doesn't provide a lot more than the status-quo other than simplifying the extensibility and maintainability of UserAgents.

To expand on the present feature set and move other parts of the system to this actor infrastructure I have the following additional design goals for Calculon:

POCO Actors

One of my lead design goals was not to force any interface or baseclass requirements on actors, i.e. it should be possible to author actors as plain old C# objects (POCO). Actors should exist as their own isolated execution environment and their functionality testable without any part of Calculon in play. Dependencies such as transport and address are completely optional and injected by signature.

Actor monitoring and restart

Another aspect I would like to see is the erlang-style let it crash philosophy. It should be possible for an actor to subscribe to another actor to monitor its health. I'm not sure what "crash" should mean at this time, since using Result as the completion handle already captures exceptions and marshalls them to the caller.

My plan is to let these semantics emerge from use cases, as I put Calculon into production.

Remote Actors

One of primary benefits of actors for concurrency is that it cleanly decouples the pieces from each other and lets you move these pieces around for scalability. Being able to serialize the messages would allow dispatchers to send messages across the wire to other nodes in the actor network. For this, I need to determine a format for serializing the LINQ expressions used in ExpressionMessage. That means that any value captured by the expression needs to be serializable itself. Unfortunately checking whether an expression can be serialzied will be a runtime rather than compile time check.

Serializable messages are desirable even for local operation to enforce the share nothing philosophy. As it stands right now, shared object references could be used as message arguments, which defeats the purpose of this system. However, for performance reasons, I will likely employ Subzero to avoid unnecessary copying.

Dynamically load code and replace Actor implementation during runtime

Once there exists remote actor capability, it is possible to traverse AppDomain boundaries easily. That means that we could launch actors in different AppDomain. Conceivably, we should be able to drop a new implementation dll into a directory, load it up and have a control actor shutdown existing actors and and subsume their capabilties with its own implementation. Since we're serializing messages, changes to an actor's implemtation or even interface do not matter, as long as the method signatures previously published still exist.

Current Status

The "needed" capabilities, except for message intercept and re-dispatch, are currently implemented, although the infrastructure is a very simple implementation with lock contention issues under load. However those limitations are no more severe than my current setup, so it's good enough to migrate to, letting me improve and expand the plumbing against a working system.

The main stumbling block is dealing with interception. Right now delivery is done by Id and Type, and for expression based messages Type is fairly binding, at least to use the message. Of course the if the primary reason to intercept messages is to create the missing recipient, the interceptor would not need to be able to unwrap the message, just re-dispatch.

The simple way to implement this is to make interceptors hook into the dispatch framework, rather than actors in their own right. They could then be tied to internals and simply be part of the mailbox matching code and spawn and insert a new mailbox when triggered. However, I would rather stick with actors for everything and make the framework as invisible as possible, which also means that capture and re-dispatch should also be possible without exposing the internals of the framework. I.e. right now nobody outside of the plumbing ever even sees an expression message instance and I'd like to keep it that way.

Since I already know that I want to have actors that can choose to accept messages based on the sender, rather than a recipient id, it's clear that I need better pattern matching capabilities for actors to expose that let them indicate their interest in accepting a message and that I need some neutral payload format that can be re-addressed and re-dispatched. So that's still one part of the puzzle I have to solve.

Fixing leaking semaphores with mod_mono

After porting my mod_mono ASP.NET MVC application to Ruby and Rails and setting up Phusion Passenger up to run the application under mono, I finally figured out how to fix the leaking semaphore issue. The real title of this post should probably be "PEBKAC or Don't assume errors are unrelated, you idiot".

Recap of the problem

The problem manifests itself as a build up of semaphore arrays by the apache process, which is visible via ipcs. When the site is first started the output looks like this:

[root@host ~]# ipcs

------ Shared Memory Segments --------
key        shmid      owner      perms      bytes      nattch     status
0x01014009 1671168    root       600        52828      48
0x0101400a 1703937    root       600        52828      25
0x0101400c 1736706    root       600        52828      35

------ Semaphore Arrays --------
key        semid      owner      perms      nsems
0x00000000 10616832   apache     600        1
0x00000000 10649601   apache     600        1
0x00000000 10682370   apache     600        1
0x00000000 10715139   apache     600        1

------ Message Queues --------
key        msqid      owner      perms      used-bytes   messages

Eventually it'll look like this:

[root@host ~]# ipcs

------ Shared Memory Segments --------
key        shmid      owner      perms      bytes      nattch     status
0x01014009 1671168    root       600        52828      48
0x0101400a 1703937    root       600        52828      25
0x0101400c 1736706    root       600        52828      35

------ Semaphore Arrays --------
key        semid      owner      perms      nsems
0x00000000 10616832   apache     600        1
0x00000000 10649601   apache     600        1
0x00000000 10682370   apache     600        1
lots more
0x00000000 11141158   apache     600        1
0x00000000 11173927   apache     600        1
0x00000000 11206696   apache     600        1

------ Message Queues --------
key        msqid      owner      perms      used-bytes   messages

At some point all ASP.NET pages will return blank pages. No errors, no nothing, .NET logging reports normal behavior, but no content is sent. And you can restart the mono processes and apache all you want, it won't come back. Sorry.

What's really wrong

Since day one i'd been receiving warnings at apache startup up, but since i didn't understand what they meant and things seemed to be working, i had been ignoring the,. Of course, that was a lie on its face. Things were clearly not working, with the leaking semaphores, but I conveniently filed the two issues as unrelated in my head and ignored them at my peril. The warning was this:

[Mon Jan 24 00:12:50 2011] [crit] The unix daemon module not initialized yet.
Please make sure that your mod_mono module is loaded after the User/Group
directives have been parsed. Not initializing the dashboard.

This warning was repeated for as many times as I had ASP.NET vhosts defined. I looked at my vhost configurations and saw nothing about users and groups and thought it was some weird mono issue and left it at that. But the actual problem was not in the vhost configuration but in httpd.conf. The problem was this default section:

# Load config files from the config directory "/etc/httpd/conf.d".
Include conf.d/\*.conf

# If you wish httpd to run as a different user or group, you must run
# httpd as root initially and it will switch.
# User/Group: The name (or #number) of the user/group to run httpd as.
#  . On SCO (ODT 3) use "User nouser" and "Group nogroup".
#  . On HPUX you may not be able to use shared memory as nobody, and the
#    suggested workaround is to create a user www and use that user.
#  NOTE that some kernels refuse to setgid(Group) or semctl(IPC_SET)
#  when the value of (unsigned)Group is above 60000;
#  don't use Group #-1 on these systems!
User apache
Group apache

Obviously User and Group are set after all vhost configs are loaded. Pretty much exactly what the warning was saying (doh). I simply moved the Include below User/Group and since then I have not seen more than 9 semaphores and I've restarted mono, rebuilt the application and hit the app with ApacheBench, the combination of which used to drive semaphores up.

Since things are working now and ASP.NET MVC under mod_mono is significantly faster than the Rails port, I'm sticking with ASP.NET MVC for production right now, monitoring semaphores to make sure this really did fix the problem.
